20′ Cygnet yacht
R6797,25
20’ Cygnet Two – Build your shallow-draft barge-style yacht with 4 berths, galley, WC, and versatile keel options for coastal and inland adventures.
Description
20’ Cygnet Two Barge Yacht Plans – Classic Style, Shallow Draft & Flexible Design
The 20’ Cygnet Two Barge Yacht combines traditional Thames sailing barge inspiration with modern versatility. Its multi-chine hull adds elegance and performance while maintaining a low draft, perfect for exploring the UK East Coast’s shallow waters and inland waterways.
Designed for comfort and practicality, the Cygnet Two features 4 berths, a small galley, and a WC compartment. The coachroof includes an optional lift-up section, giving extra headroom at anchor, making overnight trips and extended cruising more comfortable.
Builders can choose from several keel options to suit their sailing style:
-
Long shallow central ballast keel with steel bilge keels – ideal for stability in shallow waters.
-
Long shallow ballast keel with offset pivoted board – for adjustable draft in tight spots.
-
Deeper central keel without bilge or pivoted boards – for enhanced performance in deeper waters.
Construction is straightforward with plywood over frame, making this project achievable for home boatbuilders. The thoughtfully designed hull offers balance, seaworthiness, and the timeless charm of classic barge yachts, while the flexible layout adapts to your personal needs.
✅ Key Features:
-
LOA: 20’ – compact yet spacious
-
4 berths with galley and WC compartment
-
Optional lift-up coachroof for extra headroom
-
Multiple keel configurations for shallow or deep waters
-
Plywood over frame construction – ideal for DIY builders
-
Perfect for coastal cruising, estuaries, and inland waterways
20′ Cygnet two barge yacht specifications
| Description | Imperial | Metric |
|---|---|---|
| LOA | 20' | 6.1m |
| Beam | 6'10" | 2.08m |
| Hull Mid Depth | ||
| Draft | 1'7" or 3'3" | 0.48m or 1.04m |
| Sail Area | 265 sq.ft | 24.61 sq.m |
| Estimated Dry weight | 3263 lbs | 1480 kg |
| Ballast | 979 lbs | 444 kg |
| Headroom | 4'7" or 5'7" with raised roof | 1.4m or 1.7m with raised roof |
| Berths | 4 | |
| Hull Shape | Multi chine | |
| Construction method | ply over frame | |
| Plywood requirements | 27 x 9mm sheets | |
| Drawing/ Design Package | 12 x A1 drawings | 12 x A4 instructions |
| Guidance usage | Estuary, Coastal, lake | |
| Additions and alterations included with the plans |
